◆物品優點和缺點 Product features
1. 制定新(xin)奇,形狀外觀,干(gan)凈成(cheng)效好(hao);
2. 能(neng)調(diao)式風暴區分器,能(neng)將也可以爐料與很小(xiao)焊接煙(yan)塵區分,好的爐料立刻(ke)采用;
3. 具體零元件適用優異原裝進口鑄件,應用生命長;
4. 制造軸(zhou)類(lei)表面能均(jun)勻分布(bu);
5. 多鉗臺設計;進行操作流程者可一起進行操作流程噴砂。通過雇主市場需求,待選擇半手動或手動 ;可按玩家規定訂做!
1. Novel design , beautiful shape, good environmental protection effect;
2. Adjustable cyclone separator, can be used with tiny dust separation, good abrasive continue to use;
3. The main components uses the high quality import parts, long service life;
4. Machining surface evenly;
5. Program design; An operator can also operate sandblasting. we can choose manual or automatic according to customer needs.
◆適合領域 Applicable scope
板才,PC的外殼,聲響板材(cai),三(san)文治烤(kao)盤(pan)等正(zheng)等軸測圖及方體部件的噴砂精加工。
Plate, the computer case, music panels, sandwich baking dish wait for plane and workpiece of sandblasting processing.
◆主耍科技系統參數 Main technical parameters
|
系(xi)統主要參數 Model |
STR-多工位輸送式噴砂機 |
|
整個設備寬度 Complete machine size(mm) |
3000×1000×1700 |
|
上(shang)班(ban)環境 Work space(mm) |
2000×1000×800 |
|
外傳輸(shu)盡寸 Conveying the size(mm) |
500×1000×1000(2件) |
|
排塵箱長寬 Dedust box sizes(mm) |
600×600×1800 |
|
剝離 器馬(ma)達(da) Separator motor |
220V 50HZ 550W |
|
剝離(li)器功率 Separator air volume |
8.5m3/min |
|
縮(suo)小氣體源 Compressed air source |
2-8bar(kg/cm2) |
|
噴槍(qiang) Spray gun |
2把 |
|
照明(ming) Floodlight |
兩盞30W防火燈 |
|
電腦單重(zhong) Machine weight |
550kg |
